Tracalogic 3G IoT Gateway is a powerful, open-source industrial gateway designed to connect LoRa wireless networks.
| • Processor | 400MHz, 24K MIPS |
| • Memory | 16MB Flash, 64MB RAM |
| • Connectivity Options | LAN, WiFi (802.11 b/g/n), 3G, USB |
| • Interfaces | 2x RJ45, 2x USB (host + internal), DC 12V Power Input |
| • Antenna Ports | GSM / GPS External Antennas |
| • LoRa Chipset | SX1276/SX1278 |
| • Range | Up to 10 km (LoRa), 500+ meters in dense areas |
| • Max Supported Nodes | Up to 300 |
| • OS & Interface | OpenWrt Linux, Web GUI, SSH, Remote Management |
1. Versatile Deployment Options
Supports multiple connectivity options, ideal for both rural and urban installations with 3G fallback.
2. Ultra-Long Range Communication
LoRaWAN-compatible design allows communication over distances up to 10km with minimal power use.
3. Reliable and Secure
Fail-safe system design ensures consistent uptime with robust Linux OS and secure web-based controls.
4. High Node Capacity
Handles up to 300 LoRa nodes, perfect for growing sensor-based networks and complex applications.
1. Built for Harsh Environments
Rugged casing and industrial-grade components suitable for extreme weather, industrial zones, and outdoor deployments.
2. Easy to Integrate
Plug-and-play design with open API, flexible LoRa protocols, and firmware upgrade via web.
3. Future-Ready
Expandable and scalable to fit smart farm, smart grid, transportation, and city infrastructure needs.
4. End-to-End Support
From hardware setup to software updates and white-label options – we support your business every step of the way.
Programming is done via the CP2102 micro USB interface using Arduino IDE. No reset is required.
Yes, white labelling and customization are available based on MOQ.
A Nano SIM card is required.
Applications include IoT gateways, asset tracking, data logging, remote monitoring, machine learning, and more.
Yes, TL19S allows remote engine or fuel cut-off via app, platform, or SMS commands, preventing unauthorized use or theft of your vehicle.
