Tracalogic 4G IoT Gateway is an industrial-grade gateway that enables wireless communication between IoT devices and cloud services via WiFi, Ethernet, or 4G/LTE networks.
| • Processor | 400MHz, 24K MIPS |
| • Memory | 16MB Flash, 64MB RAM |
| • Connectivity Options | LAN, WiFi (802.11 b/g/n), 4G, USB |
| • Interfaces | 2x RJ45, 2x USB (host + internal), DC 12V Power Input |
| • LoRa Chipset | SX1276/SX1278 |
| • TLS Security | Supports MQTT over TLS, client/server certificates |
| • Range | Up to 10 km (LoRa), 500+ meters in dense areas |
| • Max Supported Nodes | Up to 300 |
| • OS & Interface | OpenWrt Linux, Web GUI, SSH, Remote Management |
1. Multi-Network Support
Seamless real-time communication via 4G, Ethernet, or WiFi.
2. Open Source & Customizable
Built on OpenWRT Linux for flexible configurations and scripting.
3. Ultra-Wide LoRa Coverage
Covers up to 10 km in open areas with low power consumption.
4. Cloud Integration Ready
Compatible with major IoT cloud platforms using MQTT.
1. Designed for Industrial Use
Operates reliably in harsh environments with stable connectivity.
2. LoRa + 4G in One Device
Ideal for hybrid deployments with sensor nodes spread across wide areas.
3. Comprehensive Configuration
From LTE/APN settings to Modbus TCP, fully manageable via web interface.
4. High Node Scalability
Supports large deployments with up to 300 connected sensors.
It supports 4G/LTE, WiFi, Ethernet, and USB for versatile deployment in any environment.
It can manage up to 300 LoRa sensor nodes simultaneously.
Yes, it supports MQTT protocol for integration with most cloud IoT platforms.
Absolutely. You can access it via SSH, Web GUI, or securely through MQTT with TLS encryption.
GPS functionality is available in models GW-IND-01-4GL and GW-IND-01-4GLO.
