Real-time positioning and tracking, track replaying, historical track.
| • Device Name | GPS Tracker |
| • Model | TL06 |
| • Features | Engine shut-off |
| • Device Dimension | 72mm(L)*31mm(W)*12mm(H) |
| • Device Weight | 30g |
| • Quad Band | 850/1900/900/1800MHz |
| • Voltage Input | 5 - 32V |
| • Back-up Battery | 55mAh |
| • Positioning Time |
Hot Start < 2S (Open Sky) Warm Start < 15S Cold Start < 38S (Open Sky) |
| • GPS Sensitivity | -144 dBm |
| • Tracking Sensitivity | -160 dBm |
| • Operating Temperature | -20°C ~ +70°C |
| • GSM/GPS Antenna | Built-in Design |
| • GPS Chip | MTK |
| • Real-time Tracking | Update position every 10 seconds with continuous tracking. |
| • Fast Positioning | Provide a timely positioning service after installing it. |
| • Trace Playback | Check the history trace of your vehicle to help you find useful information. |
| • User Define Geo-Fence | Users can set a range of Geo-fence on the map, and it will alarm when the device gets in or out of presetting range via APP or SMS. |
| Remotely Cut-off Petrol/Electricity | Remotely control the vehicle engine via platform, app, or sms to avoid someone driving the vehicle illegally. |
| • Sturdy Device Body | IP65 Water-resistant and dust-proof design |
| • Over-speed Alarm | When your speed is over what you set, it will send an alarm to remind you to keep safe. |
| • Disassemble Alarm | Send an alarm notification when someone removes the device. |
| • Low Power Consumption | When the device is in low power, send a message to tell you to charge it in time. |
| • Platform/APP/SMS Checking | Various methods like platform, app, sms to check asset status. |
Car, Bike, Truck and Bus Security, Fleet Management and Tracking
1. Real-Time GPS Tracking
2. Geo-Fencing Capabilities
3. Driving Behavior Monitoring
4. Anti-Theft Features
1. Easy Installation and Setup
The TL06 is designed for quick and easy installation, making it suitable for many vehicles. Its plug-and-play design reduces downtime and ensures seamless integration with existing fleet management systems.
2. User-Friendly Interface
Access real-time data and reports through an intuitive mobile app or web dashboard. Customizable alerts, reports, and user settings allow you to tailor the system to your specific needs.
3. Scalable Solution
Whether managing a small fleet or a large transportation network, the TL06 Vehicle Tracker is scalable to accommodate growing business needs. Its versatile features and integration options make it adaptable to various industries and operational requirements.
4. Comprehensive Support and Maintenance
Enjoy peace of mind with dedicated customer support and regular software updates. TL06 offers a reliable solution backed by ongoing technical assistance and system enhancements.
The Basic 4-Wired GPS Tracker is an IoT-enabled device designed to provide real-time location tracking, driving behavior analysis, and various security features for vehicles.
By offering real-time location data and driving behavior analysis, the tracker allows for continuous monitoring of vehicles, enhancing security and operational efficiency.
Yes, the Basic 4-Wired GPS Tracker is designed to be compatible with a wide range of vehicles, including cars, trucks, and other commercial vehicles.
Installation should be performed by a qualified technician to ensure proper integration with your vehicle's electrical system. For installation assistance, you can contact Tracalogic's support team at tracalogic@gmail.com or support@tracalogic.com.
Yes, Tracalogic provides comprehensive support and maintenance services for all its products, including the Basic 4-Wired GPS Tracker. You can reach their support team at tracalogic@gmail.com or support@tracalogic.com for assistance.
